Voodoo Lab PEDAL POWER 2PLUS User Manual

If you are unsure which Pedal Power output and setting to use, or
whether an effect can be powered by your Pedal Power, try search-
ing our forum at www.voodoolab.com/forum.
Specifications
Input: IEC connector
120V 50/60Hz (North America model)
100V 50/60Hz (Japan model)
230V 50/60Hz (Europe/Australia model)
Model and input power are marked on the bottom of unit.
Outputs: 5.5x2.1mm barrel connectors center negative
Short circuit protected.
DIP Switch: NORMAL
Output DC Voltage Max current
1-4 (ACA) 9V 100mA
5-6 (L6) 9V 250mA
7-8 (SAG) 9V 100mA
DIP Switch: ON
Output DC Voltage Max current
1-4 (ACA) 12.3V 60mA
5-6 (L6) 14.5V / 12V (unregulated) 50mA / 200mA+
7-8 (SAG) Adjustable 4V - 9V 100mA
Physical: 6.0" wide x 3.4" deep x 1.75" tall (152x86x45mm)
Weight 2 lbs. (0.9 kg).
Special: Toroidal power transformer.
Auxiliary AC outlet, 200 watts max.

Voodoo Lab PEDAL POWER 2PLUS Specifications

General

Output Ports	8
Output Voltage	9V, 12V
Output Current	100mA, 250mA
Weight	2 lbs
Input Voltage	120V
Input Frequency	50/60Hz
Topology	Isolated
Dimensions	6 x 3.4 x 1.75 inches (152 x 86 x 44 mm)
Transformer	Toroidal
Cables Included	Yes, various DC power cables
