cable. You can purchase these cables from your dealer or directly
from Voodoo Lab.
The voltage doubler cable combines two Pedal Power outputs in
series. When outputs are combined in series, you get the combined
voltage of both outputs. For example, if you connect this cable to
two 9V outs, you will get 18V. If you connect it to two 12V outs,
then you get 24V. This does not change the current capability. If you
use 100mA outputs, you still get a maximum of 100mA combined.
The current doubler cable combines two outputs in parallel to
increase the current capability. Using this cable on outputs 5 and 6
with both switches set away from NORMAL will provide approxi-
mately 12V at 400mA. That’s the correct setting for pedals that come
with a 9V unregulated adapter, such as the Eventide TimeFactor.
More About Cables
The DC power cables supplied with your Voodoo Lab Pedal Power
are suitable for most common pedal effects. If you need additional
cables they are available from your dealer or directly from
Voodoo Lab. If you need cables of a different length, with reversed
polarity, or with a special connector, contact us and we can provide
them for you.
Visit www.voodoolab.com/cables for more information.
Operation
Using the above information, connect the DC power cables between
the Pedal Power outputs and the power jacks on your pedal effects.
Now connect the AC power cord from the AC power input jack on
the Pedal Power to a suitable AC outlet. The Pedal Power’s red LED
power indicator will light, telling you that it’s working properly.

Voodoo Lab PEDAL POWER 2PLUS Specifications

General

Output Ports	8
Output Voltage	9V, 12V
Output Current	100mA, 250mA
Weight	2 lbs
Input Voltage	120V
Input Frequency	50/60Hz
Topology	Isolated
Dimensions	6 x 3.4 x 1.75 inches (152 x 86 x 44 mm)
Transformer	Toroidal
Cables Included	Yes, various DC power cables
