Voodoo Dragon
3
2. Hardware installation
Note: Make sure that the plug has been removed from the
outlet before you open the casing. You risk injuring
yourself or damaging your system if you work on the PC’s
internal components when the PC is still connected to the
electrical mains. ATX systems can activate themselves
when a card is added or removed.
1. Turn off your PC.
2. Remove the plug from the outlet.
3. Remove the casing from the computer (if necessary, consult the
user manual of the computer).
4. Remove the metal cover-plate from the available PCI slot.
5. Plug the Voodoo Dragon into the available PCI slot and fasten
the card.
6. Re-attach the casing to the PC.
7. Disconnect the monitor plug from the computer.
8. Connect plug E to connection C (the VGA exit of your computer).
9. Connect plug D to connection B.
10. Connect the monitor cable to connection A.
11. Turn on the computer.
