FEATURES
REMOVABLE GRILLE
For easy cleaning.
FINGER FRIENDLY DESIGN
Resists curious ngers.
DIRECTABLE
AIRFLOW
Direct the
airow where
you want it.
Model 62 (not
available in Japan)
MULTIPLE SPEEDS
Speed setting for every
comfort level.
AIR INLETS
Signature inlets and powerful
motor to move more air.
SILICONE FEET
Non-marking feet added
for stability.
Save energy by maximizing the performance of heating and cooling systems. When you use a Vornado Air Circulator, you will not have to
set your summertime thermostat as low or your wintertime thermostat as high.
602
CONTROL
KNOB
52
CONTROL
KNOB
62
CONTROL
KNOB
(Not available
in Japan)
(Not available
in Japan)
CONTROLS
HIGHMED OFF
LOW
HIGHMED OFF
LOW
HIGHMED OFF
LOW
STAND ASSEMBLY & ADJUSTMENT
(MODEL 602 / NOT AVAILABLE IN JAPAN) No tools required.
STAND ASSEMBLY
1. Insert power cord (A) into
the top of Pole and pull
through the bottom.
2. Push the Circulator Head
into the Pole. Push until
the Lock Release Button (B)
snaps through the Hole (C).
3. Remove the Fastening
Nut (D) secured on the
underside of the base.
Rotate Fastening Nut
counter-clockwise to
remove.
4. Assemble Legs onto the
base of Pole by pushing
each Leg onto the grooves
(E). Replace Fastening Nut
(D) by rotating clockwise to
secure all the Legs in place.
HEIGHT ADJUSTMENT
(85–110 CM)
1. Support the Circulator Head
(A) with one hand. Use your
other hand to loosen the
Adjustment Collar (B) by gently
rotating it counter-clockwise.
2. Slowly raise or lower the
Pole to the desired height
and secure into position by
rotating the Adjustment Collar
clockwise until tight.
Note: Before adjusting the
height or rotating the head,
check that the power cord is
not tangled and able to move
freely.
After adjusting height, ensure
that the Adjustment Collar is
fully tightened and engaged to
ensure Circulator Head does
not rotate and bind power
cord.
E
C
B
D
A
A
B
