PRIMEROS PASOS
ENSAMBLAJE DE LA BASE AND LEG Se necesita un destornillador.
BASE
LEGS (4)
BASE PLATE
1. Remove the base plate.
2. Insert a leg into the slot. Repeat until all four legs are inserted.
Legs are universal and can t in any slot.
3. Align base plate to bottom of unit. There is an alignment pin
located on bottom of unit and an alignment recess on base plate.
To ensure correct assembly, position base plate onto bottom of unit
with pin and recess aligned.
4. Attach base plate using four screws provided (included in bag with
this manual).
ADVERTENCIA - Peligro de asxia. Mantenga las piezas
pequeñas, como los tornillos, fuera del alcance de los niños y las
mascotas.
CÓMO USAR
OSCILACIÓN
ENCENDIDO/APAGADO
GREEN LED LIGHT
VELOCIDAD
/
1. Toque para encender. When unit is
powered ON, the green LED will illuminate.
2. Select desired fan speed by pressing to
increase fan speed or to decrease fan
speed. Speeds are Low, Medium Low,
Medium, Medium High and High.
3. Presione para activar y desactivar la
Oscilación. The default oscillation range is
90°. To activate 180° oscillation range, press
and hold oscillation button for 3 seconds.
The green LED will ash when oscillation
angle has successfully been changed.
Note: After unit is unplugged and then plugged
in again, the unit will oscillate until it locates its
“default” position centered between the two
front legs.
