Vortech MP10 - Step 4: Place Dry Side on Aquarium

STEP 4: Place Dry Side on Aquarium
•
Place the rubber spacer directly on the wall of the
aquarium at the desired location (Figure B).
• The included rubber spacer must be used between
the dry side and the aquarium wall for thicknesses
of 1/8” (3mm) and 3/16” (5mm).
• The rubber spacer is NOT needed for thicknesses
of 1/4” (6mm) or 3/8” (10mm).
• Position the dry side so the cord points straight up
in the 12 o’clock position (Figure C).
• Tie the cord to the mounting tab using a zip tie
(Figure C). Trim the excess end of the zip tie.
Never place the dry side in the aquarium.
Failure to use the rubber spacer can damage the
pump, which will NOT be covered under warranty.
5
Figure A
Figure C
Figure B
