10
5
7
3
2
6
4
9
8
10
1
1
4
Timer
Buttons and LED indicators :
1
Select operating state (clockwise):
2
Continuous
3
Setting mode
4
Operation via time switch
5
Permanent stop
6
Time
7
LED ring of the runtimes (see gure 2, p. 11)
8
Select times (time and runtimes)
9
Pump running (LED lights up) or is off
(LED does not light up)
10
Conrm time/conrm or delete runtimes
When it is connected to the electricity mains for the rst
time, the pump runs continuously (delivered condition –
LEDs
2
,
6
and
9
light up, see gure 1).
Shortest runtime is 30 minutes.
When the power supply is interrupted, the time stops
(no power reserve). The saved runtimes
7
are retained.
If the power supply is restored, the pump runs in the
operating state that was last set,
6
ashes. The time
has to be updated.
Setting the time and runtimes:
Press
1
until
3
lights up.
Use
8
to set the red LED to the current time and conrm
with OK
10
.
9
no longer lights up. The green LED in the
section 0.00 h to 0.30 h ashes.
With
8
, set the LED to the required runtime and conrm
with OK
10
. The LED jumps directly to the next runtime.
Conrm once again with OK
10
or skip with
8
(etc.). The
LED ring runs more quickly if
8
is held down.
End setting with
1
. The saved runtimes are displayed.
The pump runs according to the set runtimes,
4
lights
up.
