DIAMON DBACK
™
HD 2000
6 7
Low Battery Icon
The Low Battery Icon comes on at
25% and stays on until there is no
power or the battery is replaced.
Adjusting the Diopter
Rotate the Diopter clockwise or counterclockwise until the
image is in focus. This may have to be adjusted slightly
when viewing at different distances.
Low Battery
Attaching the
Wrist Lanyard
The Lanyard provides a secure
way to carry your rangefinder.
Utility Clip
The Diamondback
™
HD 2000 comes with a Utility Clip
on the unit’s left-hand side. You can switch Utility Clip’s
side by unscrewing the 2mm hex screws on the left-hand
side, and the 2mm hex screws on the unit’s right-hand
side. Reinstall the Utility Clip on the unit’s right-hand
side and replace the plate and 2mm hex screws on the
left-hand side.
2mm Hex ScrewsUtility Clip
Loop the Lanyard through
the attachment socket.
