Vortex V-V500 - Page 12

Assembly Instructions
Step 7
Connect Pedals (31 Right & Left) to Cranks as shown in above diagram.
Note: The left one is marked "L" and right one marked "R". Fasten the left pedal by turning in an anti-
clockwise direction and fasten the right pedal by turning in a clockwise direction.
11
Clockwise
Anti-Clockwise
