Vortex V-V500 - Exploded Parts List

Key No.
Description
QTY
Key No.
Description
QTY
1
Main Body
1
31
Pedal
1
2
Front Stabilizer
1
32
17mm Elastic Damping Ring
1
3
Rear Stabilizer
1
33
17mm Corrugated Gasket
1
4
Saddle Post
1
34
Level Foot Lock Bracket
2
5
Saddle Support Frame
1
35
Level Foot
4
6
Seat Lock Bracket
1
36
60mm End Cap
4
7
Handle Post
1
37
Transport Wheel
2
8
Handle
1
38
40×20×1.5mm Flat End Cap
2
9
Saddle
1
39
23.5×53.5×1.5mm Flat End Cap
4
10
Brake Knob
1
40
Crank Cover
2
11
Brake Sleeve
1
41
Φ25x2mm Cone End Cap
4
12
Brake Spring
1
42
Chain / 104Joints / Joint length
12.7mm
1
13
30×60×145mm Sleeve
2
43
6203 Bearing
2
14
M10 Knob
1
44
6001 Bearing
2
15
M16 Lock Knob
2
45
Axle Sleeve
1
16
Water Bottle Holder
1
46
Fly Wheel Sleeve
1
17
Console
1
47
Gear wheel
1
18
Sensor Wire
1
48
42
×
5T
×
m33
×
1mm Lock Ring
2
19
Reed
1
49
Fly Wheel Axle
1
20
Handle Cover
1
50
17×12.5×2mm Washer
2
21
Outer Chain Cover
1
51
20×12.5×5mm Washer
2
22
Inner Chain Cover
1
52
28mm Nylon Washer
1
23
Fly Wheel Cover
2
53
M12×1/5Tmm Pyramidal Face Hex
Nut
4
24
Fly Wheel
1
54
Tension Bolt
2
25
Brake
1
55
M6 Hex Nut
4
26
Brake Holder
1
56
M12 Dome Head Nut
2
27
Bracket
1
57
M8x40mm Hex Bolt
2
28
Bearing Block
1
58
M5x5mm Philips Bolt
2
29
Chain Wheel Assembly
1
59
M5x10mm Philips Bolt
2
30
Crank
1
60
M5x30mm Philips Bolt
2
