Vortex V-V500 - Assembly Instructions

Assembly Instructions
Step 1
5
a. Attach Front stabilizer (2) to Main Body (1) using 2 x 20mm Allen bolts (61), 2 x Ø10mm Spring
washers (63) and 2 x Ø10 Curved Washers ( 67).
b. Repeat step a to install Rear stabilizer (3) to Main Body (1).
C. Level the machine
The user can tighten or loose 2 x Level Feet (35) to level the machine if needed. Tighten 2 x Level
Note: Level Feet (35) and Level foot lock nuts (34) are pre-fitted.
foot lock nuts (34) to make the machine stable before starting workout.
