Assembly Instructions
Step 2
6
a. Attach the Saddle Support Frame (5) onto the Saddle Post (4),secure with Lock Knob (14).
b. Loosing M16 Lock Knob (15) and remove, insert Saddle Post Assembly (4&5) into the rear opening
tube of the Main body (1).
c. Adjust the Saddle Post Assembly (4&5) to your desired height, then refit and tighten the Lock knob
(15).
d. Loosing Lock Knob (14) to select your desired forward or backward position, then tighten the Lock
knob (14).
5
14
