EQUIPMENT SPECIFICATIONS AND SIZING TABLES
REFER TO Small-D design Guide for additional duct sizing options.
TABLE 1 - Air Handler Selection Table
Model
ZC24L
ZCT24L
ZC30L
ZCT30L
ZC36L
ZCT36L
ZC42L
ZCT42L
ZC48L
ZCT48L
ZC60L
ZCT60L
ZC100
Min. 4” Branches per Zone 6 8 9 11 12 15 15
Min. 14”x8” Return Air Grilles 5 7 8 8 9 10 11
Heating Capacity
1
(Btu/h)@130ºF
50,000 58,000 65,000 65,000 69,000 73,000 91,000
Heating Capacity
1
(Btu/h)@140ºF
54,000 63,000 70,000 70,000 75,000 80,000
106,000
Heating Capacity
1
(Btu/h)@160ºF
66,000 80,000 90,000 90,000
97,000 103,000 135,000
Heating Capacity
1
(Btu/h)@180ºF
81,000 99,000 110,000
110,000 117,000 125,000 164,000
Air flow rate at full heating
(cfm)
1000 1200 1400 1400 1600 1800 2000
Max. Ext. Static Pressure (“wc) 1.3 0.6 1.1 1.1 1.2 0.7 0.8
USGPM Heating 6 6 6 6 6 6 10
Cooling Capacity
2,3
(Tons) 2.0 2.5 3.0 3.5 4.0 5.0 5.0
Blower Motor Full Load
(Amps)
5.5 5.5 7.7 7.7 9.6 9.6 9.6
Circulator Full Load (Amps) 0.8 0.8 0.8 0.8 0.8 0.8 1.4
Cabinet Width (in.) 22 22 22 22 22 22 22
Cabinet Depth (in.) 25 25 25 25 25 25 25
Cabinet Height (in.)
(Regular ZC)
44 44 44 44 44 44 65
Cabinet Height (in.)
(Tall ZCT)
65 65 65 65 65 65 N/A
Supply Air ( per Zone) 8”Φ 8”Φ 8”Φ 10”Φ 10”Φ 10”Φ 10”Φ
Return air (in.) 18x23 18x23 18x23 18x23 18x23 18x23 18x23
Supply and Return Water
Connections (in.)
3/4 3/4 3/4 3/4 3/4 3/4 1
Weight-air handler only
(pounds)
150 150 155 170 175 175 200
1. capacity based on 70ºF return air, high speed and 12.5 feet length per branch at 4”
diameter. Two 3” branches = one 4”, two 4” = one 6”. Do not exceed grille rating. Higher
static pressure/reduced heating capacity available at lower airflow.
2. Regular ZC requires external cooling coil (extra) in the return air duct.
3. Tall ZCT can use cooling A-coil supplied by others. Cabinet opening is 20W x 24D x 21H.
