Vortice QE Series User Manual

91
25
QE 60/35 LL TP HCS
A
123LN
C
E
F
L
N
(
**)
B
B
Main terminal block
D disable switch
A
Room lightE
Main bipolar switchF
35m3/h switch
D
C60m3/h switch
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
(
*)
26
QE 60/35 LL T PIR
A
123LN
C
L
N
B
B
Main terminal block
35m3/h switch
A
Main bipolar switch
C
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(*)
