Vortice QE Series - Page 92

92
27
QE 100/60 LL
A
B
Main terminal block
C100m3/h switch
123LN
A
Room lightD
Main bipolar switch
D
E
E
L
N
60m3/h switch
B
C
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(*) (*)
28
QE 100/60 LL T
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(**) Timed input
A
B
Main terminal block
C100m3/h switch
123LN
A
Room lightD
Main bipolar switch
D
E
E
L
N
60m3/h switch
B
C
(*)(*)
(**)
