1345340 - 11.2022 - V7
INSTRUCTION MANUAL VOSS.SONIC 2800
DE
EN
FR
IT
NL
SV
ES
PL
3 INTENDED USE
The VOSS.sonic 2800 is used to repel pests and unwanted animals indoors or outdoors. No other
use is permitted. Do not use the device in living rooms or rooms where people are present. Indoor
operation is permitted for sheds, garages or cellars. The device is intended for private use only
and not for commercial use.
Info
There is no 100% guarantee that all animals will be successfully deterred, as each animal
reacts differently to ultrasonic signals.
4 CONTENTS
The contents:
∙
1x VOSS.sonic 2800 ultrasonic animal repeller
∙
1x plastic mounting stake,
∙
1x 6V mains adapter (only for Art: 45345.UK)
∙
1x operating instructions
5 TECHNICAL DATA
∙
Area covered by ultrasonic sound: ca. 200 m²
∙
Frequency range: 14–26 kHz
∙
Range of the motion detector: 90° angle, approx. 16 m
∙
Type of flash: LED
∙
Power supply:
Batteries: 4x AA 1,5 V Mono D battery
Mains adapter: Input 100 - 240 V AC 50/60 Hz
Output 6 V DC 1000 mA
∙
Standby consumption: 0.34 mA
∙
Consumption on activation: 416 mA with flash, 268 mA without flash
∙
Max. ambient temperature: 5–40 °C
∙
Max. humidity: 10–90 %
∙
Protection class: IP X4
Dimensions and weight
Dimensions without stake (LxWxH) approx.: 185 mm x 124 mm x 91 mm
Dimensions with stake (LxWxH) approx.: 403 mm x 124 mm x 91 mm
Weight (without batteris and stake) approx: 357 g
Weight (without batteries with stake) approx: 393 g
6 DEVICE OVERVIEW
No Description
1 Speaker
2 Flash
3 Motion detector
4 Control-LED
5 On/Off switch & frequency selector
6 On/Off ash switch
7 Mains adapter connection
1
2
3
4
5
6
7
