1. INPUT 1 Indicator
To indicate the INPUT 1 THRU is active.
When the INPUT 1 over 2V the PEAK indicator will light
2. MIC Indicator
To indicate the MIC is active.
3. INPUT 1 Source switch
Can switch between AUX or LINE/PHONO1.
4. INPUT 2 Source switch
Can switch between MIC or LINE/PHONO2.
5. Master Volume Control
This rotary knob is is used to control the master output level (volume). To avoid distorted output try to maintain
an verage output signal level.
To avoid speaker damage that may be caused by excessive volume, be sure this adjustment always set to
zero before turning the unit on.
