Option 1 – The data bus connector will be configured to work with modules that use the ADS
Option 2 – The data bus connector will be configured to work with modules that use the DBI
Feature 16: Dome Light Delay Timer
Function: Set the delay timer when using the vehicle’s Dome Light as a door trigger.
Setting Choices:
Option 1 – OFF / Delay Timer will be OFF or use the programmed See page 25 for dome light delay programming procedure
Option 2 – 15 seconds, System will wait 15 seconds before monitoring the door trigger
Option 3 – 30 seconds, System will wait 30 seconds before monitoring the door trigger
Option 4 – 45 seconds, System will wait 45 seconds before monitoring the door trigger
Option 5 – 60 seconds, System will wait 60 seconds before monitoring the door trigger
Option 6 – 120 seconds, System will wait 120 seconds before monitoring the door trigger
Feature 17: Alarm Trigger Length
Function: Set the length of time the Alarm Notification will sound for each cycle. Setting Choices:
Option 1 – 30 seconds, System will Alarm Cycle will sound for 30
Option 2 – 45 seconds, System will Alarm Cycle will sound for 45
Option 3 – 60 seconds, System will Alarm Cycle will sound for 60
Option 4 – 90 seconds, System will Alarm Cycle will sound for 90
Option 5 – 120 seconds, System will Alarm Cycle will sound for 120
Note: The system will check the trigger inputs between each Alarm Cycle. If the trigger input is still active the system will notify the user with another cycle.
Remote Start Control (Bank 3)
See page 23 for Programming Instruction.
Feature Bank 3
Options
1 Chirp 2 Chirp 3 Chirp 4 chirp 5 Chirp 6 Chirp
Features
1 Defrost Output Pulsed 10min RS Runtime
2 RS Start Notification ON OFF
3 RS Runtime 15min 20min 45min 60min 5min 10min
4 RS Parking Lights Steady Flashing
5 Engine Confirmation Tach Voltage Data Hybrid
6 Voltage Level >0.5v 84 Start <0.5v B4 Start
7 Ignition 2 Output Ignition Accessory Start
8 Ignition 3 Output Ignition Accessory Start
9 Accessory Output Accessory Ignition Start
10 Transmission Auto Manual
11 Max Crank Time 0.8sec 1.0sec 1.5sec 2.0sec 3.0sec 4.0sec
12 Diesel Delay OFF Diesel 5 Diesel 10 Diesel 15 Diesel 20 Diesel 30
13 Temperature Start OFF 14F 5F OF -4F -14F
14 Crank Duration Averaging Preset
15 RS Shock Override Shunt until Clear Shunt RS Cycle Shunt From TX
16 Turbo Timer OFF 3min 5min 10min
17 Start Activation Two Press One-Press Three Press
18 RS Lock Function No Change UL Before L After UL Before Start Lock After Start
19 Factory Disarm Output Single Pulse Double Pulse 350ms 500ms 800ms
Same As
Bank 2, Fl
20 Additional Unlock Pulse No Pulse IGN, ACC, GWR IGN,ACC,GWR,PASD
Feature 1: Defrost Output Duration
Function: Set the Defrost output to activate for a set time.
Setting Choices:
Option 1 – Output pulses for 1 second.
Option 2 – Output stays on for 10
Option 3 – Output stays on for the duration of the Remote Start Runtime.
Feature 2: Remote Start Notification
Function: Set remote start activation confirmation beeps on or off.
Setting Choices:
Option 1 – On – System emits an audible beep when remote start is
Option 2 – OFF -System remains silent when remote start is
Feature 3: Remote Start Run Time
Function: Set the maximum remote start run time if the vehicle is not entered after activation.
Setting Choices:
Option 1 – The engine will run for 15 minutes.
Option 2 – The engine will run for 20 minutes.
Option 3 – The engine will run for 45 minutes.
Option 4 – The engine will run for 60 minutes.
Option 5 – The engine will run for 5 minutes.
Option 6 – The engine will run for 10 minutes.
Feature 4: Remote Start Parking Light Duration|
Function: Set parking light output to turn on or flashlights during remote start.
Setting Choices:
Option 1 – Lights remain on during remote start.
Option 2 – Lights flash during remote start.
Feature 5: Engine Confirmation Mode
Function: Determine how the system knows if the remote start was successful. Setting Choices:
Option 1 – Determined by measurement from the Purple/White Tach Input
