Installation option - converting
from desktop to wall mount position
To mount the telephone base on the wall
1. Unmount the base stand from the telephone
base. Put the corded handset aside.
2. Turn the telephone base over with the
bottom side facing up. Align the grooves
with the wall mount bracket. Slide the wall
mount bracket up.
3. Connect the telephone as described in
"Telephone base installation" on page 9,
but connect the short telephone line cord
instead. Place the cords in the associated
cable ducts.
4. Mount the telephone base on the wall by
positioning the eyelets on the telephone
base and the mounting bracket against the
mounting studs. Then slide the telephone
base down on both mounting studs until it
locks into place.
5. Replace the handset on the telephone base
cradle.
To remove the wall mount bracket from
the telephone base
Simply slide the wall mount bracket down and
lift it from the telephone base.
