Telephone base and charger installation
Install the telephone base and charger as shown below.
If you subscribe to digital subscriber line (DSL) high-speed Internet service through
your telephone line, make sure you install a DSL filter (not included) between the
telephone line cord and telephone wall jack. Contact your DSL service provider for
more information.
Use only the power adapters supplied with this product. To order a replacement, visit
our website at www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or call 1 (800) 267-7377.
The power adapters are intended to be correctly oriented in a vertical or floor mount
position. The prongs are not designed to hold the plug in place if it is plugged into a
ceiling, under-the-table or cabinet outlet.
•
•
Telephone base
Charger
Telephone line cord
Telephone wall jack
A DSL filter (not
included) is required
if you have DSL
high-speed Internet
service.
The DSL filter must
be plugged into the
telephone wall jack.
CAUTION:
If you subscribe to telephone service from a cable company or a VoIP service
provider, contact your cable/VoIP service provider for more information.
Electrical outlet
(not controlled
by a wall switch)
Charger
adapter
Electrical outlet
(not controlled
by a wall switch)
Telephone
base power
adapter
