EN - 10
SIP Corded Trimstyle 1-line
CTM-S2315
Telephone base installation
Installation option - wall mount position
To mount the telephone base on the wall
1. Install the telephone base as shown below.
2. Put the corded handset aside. On the telephone base, place a coin in the slit of the wall mount
clip and rotate a half turn (180°).
• It locks into place with the protruding edge pointing towards the upper edge of the
telephone base. This protruding edge holds the corded handset when the phone is
mounted on the wall.
Ethernet cable wall jack
Ethernet cable jack
Coiled handset
cord jack
Ethernet cable
