EN - 9
Installation
SIP Corded Trimstyle 1-line CTM-S2315
Telephone base installation
Installation option - desktop position
1. Turn the telephone base over with the bottom side facing up. Insert the base stand into the
lower grooves on the telephone base until they lock securely as shown below.
2. Connect both the ethernet cable and coiled handset cord to the telephone base and route
them along the wire ducts accordingly. Install the telephone base as shown below.
ethernet cable wall jack
Ethernet cable jack
Coiled handset cord jack
Ethernet cable
Power adapter
(not included)
