Installation
49
Installation
SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P
Installation option - converting from desktop to wall mount position
To mount the accessory Petite on the wall:
Set aside the handset. On the accessory Petite cradle, place a coin in the slit of the wall mount clip and rotate a half turn
(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the accessory Petite. This
protruding edge holds the corded handset when the phone is mounted on the wall.
Press the large tab on the mounting bracket to remove it from the upper groove on the accessory Petite.
Turn the mounting bracket upside down. Insert the small tabs on the mounting bracket into the upper slots on the accessory
Petite. Then press the large tab on the mounting bracket and rmly push it into the lower groove on the accessory Petite.
Mount the accessory Petite on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the
accessory Petite down on both mounting studs until it locks into place. Place the handset on the accessory Petite cradle.
1.
2.
3.
4.
Protruding edge
