Installation

Handset battery installation

Install the battery as shown below.

Plug the battery connector securely into the socket inside the handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then

rmly push downward until all the tabs lock in the grooves. Then install the screws at both ends of the handset.

Replace a handset battery

Use a 5 mm standard screwdriver to open the screw cover and remove the screw.

Insert the screwdriver in the provided slot and then twist and lift to open the bottom part.

-OR-

Open the bottom part manually at the recessed area to avoid scratching the plastic.

Use your thumb to slide along the sides of the handset carefully to release the tabs on the handset cover from the slots on the

sides of the handset. Then gently detach the handset cover from the handset.

Unplug the battery connector from the socket and then remove the battery from the handset battery compartment.

Follow Step 2 to Step 4 in Handset battery installation above to install a new battery.

1 2 3

FCC ID

BY 1021

Screw

cover

CAUTIONS:

There may be a risk of explosion if a wrong type of handset battery is used. Use only the supplied rechargeable battery (BT264392/BT266342)

or replacement battery (BT266342). To order a replacement, call 1-888-907-2007.

FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

Dispose of used batteries according to the information in The RBRC

seal on page 81.

•

Installation

SIP contemporary cordless 1-line/2-line accessory handset - CTM-C4401/CTM-C4501/

CTM-S241SD/CTM-S242SD

BY 1021

Recessed area
