4.0. Assembly instructions – Vuly Quest
1
STEP
A.
B.
Insert a 2-hole Climbing Rail into the kinked
end of a Curved Climbing Rail, and a 3-hole
Climbing Rail into the straight end of the
Curved Climbing Rail.
Make sure that there are three large holes
on one side of the bend, and six on the
other.
Repeat for the remaining three different
Climbing Rails.
A
B
ALL SIZES:
ENSURE THAT AS YOU ASSEMBLE THE PRODUCT, YOU FIRMLY TIGHTEN ALL NUTS AND BOLTS, UNLESS DIRECTED.
PRE-ASSEMBLY
You will require the following: • Ladder • Rubber mallet • Tape measure or ruler
2x Short Shade Tube2x Long Shade Tube1x Shade Cover
5x Tension Hook4x Shade Joiner
SHADE COVER
MEDIUM BOX
5x i-Bolt
