19
Secure your completed Quest to the ground with the Anchors provided.
Ensure that all bolts are firmly secure.
Insert the completed flip sections into the T-Joiners
around the frame, as indicated below for your model.
Important: Make sure the outer sections are positioned
at 45º, relative to the climbing frame section.
A. B.Insert i-Bolts at all four top corners of the Shade Tubes,
and a fifth at the bend of one Long Shade Tube.
With two people: Attach the Shade Cover using
Tension Hooks, as shown for your model.
You have assembled your Quest monkey bar.
CONGRATULATIONS!
ALL SIZES
24
STEP
ALL SIZES
25
STEP
ALL SIZES
26
STEP
