11
Frame
1
STEP
2
STEP
A. Connect each Lower Frame Tube A to a Lower
Frame Tube B. Lower Frame Tubes are those
with Leaf Spring holes.
B. Connect each Upper Frame Tube A to an
Upper Frame Tube B. Ensure that the push
buttons lock these components together.
Warning:
Ensure that all push buttons are firmly secured and
protruding from the Frame Tubes. A great deal of force is
placed on these components; push buttons that are not fully
locked may cause damage and injury.
A. Lay out each Lower Frame Tube in a circle, ensuring that the
Leaf Spring holes are facing upwards. Place the Upper Frame
Tubes around them. Ensure that all drainage holes are facing
downwards.
B. Position a Joiner Pole and two Leaf Springs in the gaps around
the Frame Tubes.
B
A
A
To Next Page
