9
4.0. Installation
4.1. Location planning
• Do not burry the trampoline into the ground.
• Place the trampoline on a flat, level surface with impact attenuating
properties – such as grass.
• Ensure that the trampoline is sufficiently stable, to prevent the
trampoline from tipping over or blowing away. Sandbags or pegs
may be suitable anchorage devices.
• Keep a minimum of 27 ft overhead clearance, when measured
from the bed height, to prevent users from inadvertently contacting
overhead hazards – such as electric wires, tree limbs and clotheslines.
• Maintain a minimum clearance of 7 ft on all sides of the trampoline.
This area should not include concrete, bitumen, brick or other hard
surfaces, as these can cause serious injuries if users fall off the
trampoline.
• Do not locate the trampoline on top of other objects or store anything
underneath the trampoline bed.
• Keep the area around and underneath the trampoline clear. Place
the trampoline away from walls, structures, fences and other play
areas.
• Place the trampoline in a well-lit area.
Correct Installation
Incorrect Installation
4.2. Parts checklist
WARNING:
M
3x BOX A
(L) 960mm (W) 250mm (H) 245mm
1x BOX B
(L) 710mm (W) 565mm (H) 295mm
1x BOX C
(L) 730mm (W) 490mm (H) 200mm
Frame tubes, Leaf Springs,
Net poles
Joiners Jump mat, Safety net, Skirt
L
4x BOX A
(L) 960mm (W) 250mm (H) 245mm
1x BOX B
(L) 940mm (W) 565mm (H) 295mm
1x BOX C
(L) 850mm (W) 480mm (H) 240mm
Frame tubes, Leaf Springs,
Net poles
Joiners Jump mat, Safety net, Skirt
XL
5x BOX A
(L) 960mm (W) 250mm (H) 245mm
2x BOX B
(L) 590mm (W) 565mm (H) 295mm
1x BOX C
(L) 1000mm (W) 470mm (H) 225mm
Frame tubes, Leaf Springs,
Net poles
Joiners Jump mat, Safety net, Skirt
