To Next PageTo Next PageWhy is hydraulic fluid leaking from my Wabtec Ricon TITANIUM S Lifting Systems?
Hydraulic fluid leaks can occur due to a loose hydraulic fitting. Ensure the fitting is properly tightened. Alternatively, a hydraulic component may be defective, in which case you should discontinue use of the lift and have repairs made by a qualified service technician or Ricon dealer.
How to fix a Wabtec Ricon TITANIUM S rollstop that does not open?
If the rollstop on your Wabtec Lifting Systems is not opening, it may be due to an obstruction of the rollstop release latch. Raise the lift and remove any obstruction that you find.
What to do if Wabtec Ricon TITANIUM S Lifting Systems lift functions have no operation?
If the lift functions are not working, several issues could be the cause. First, check if the control system circuit breaker has tripped and reset it if necessary. Also, the backup pump manual release valve may be open; turn it clockwise until it is slightly snug. Low hydraulic fluid could also be the problem; ensure the pump hydraulic fluid level is at the required FULL level while the platform is at ground level, and add Texaco 01554 Aircraft Hydraulic Oil or equivalent U.S. mil spec H5606G fluid if needed. Finally, air trapped in the hydraulic system can prevent operation; purge the system by operating the lift through its maximum range of travel for at least four complete cycles. Note that a hydraulic hose or fitting leak may also cause this problem, in which case you should contact a ...
What to do if Wabtec Lifting Systems lift functions have abnormal operation?
Abnormal operation of lift functions can stem from several causes. Check for any obstruction in the lifting frame and remove it, inspecting for damage. Ensure the backup pump manual release valve is not open by turning it clockwise until slightly snug. Low hydraulic fluid may also be the issue; with the platform at ground level, confirm the pump's hydraulic fluid level is at the FULL mark, adding Texaco 01554 Aircraft Hydraulic Oil or equivalent U.S. mil spec H5606G fluid as needed. Lastly, trapped air in the hydraulic system can cause this; purge the system by running the lift through its maximum range of travel for a minimum of four complete cycles. (For vehicles that do not use full travel of lift, the maximum range of travel is accomplished by raising vehicle on a service hoist or ramp...
Contact information and support resources for Ricon products.
Details the warranty terms, conditions, and exclusions for Ricon Titanium lifts.
Instructions for receiving and inspecting the product for shipping damage.
Essential safety guidelines for installation, operation, and maintenance.
Identifies and illustrates the key components of the Ricon lift system.
Guidelines for selecting lift location and ensuring vehicle compatibility.
Procedure for positioning the lift within the vehicle doorway.
Specifies vehicle door opening dimensions for S-Series and K-Series lifts.
Principles for properly mounting and fastening the lift's baseplate assembly.
Specific instructions for installing the lift into bus vehicles, including clamping bars.
Steps for connecting the lift's electrical system, including circuit breakers and wiring.
Procedure for installing the main circuit breaker for the lift's power system.
Instructions for routing and connecting the main power cable from the battery.
Guidance on establishing proper ground connections for the lift system.
Instructions for connecting the lift's control pendant to the pump chassis.
Details on installing the interlock system for vehicle safety and lift operation.
Procedures for calibrating lift functions after installation.
Steps to adjust limit switches for proper lift operation and cutoff points.
Procedure for leveling the platform for optimal rollstop function.
Adjusting the folding linkage for K-Series split platforms for proper alignment.
Tightening the outer rollstop barrier on K-Series lifts using folding brackets.
Testing and adjusting the pressure switch to prevent folding with load.
Final checks to ensure all vehicle components and lift operations are correct.
Checklist to verify safe operation and compliance with FMVSS standards.
Instructions for lubricating lift components to ensure smooth operation and longevity.
Guidelines for cleaning the lift to protect surfaces and maintain pivot points.
Recommended inspection intervals and tasks for lift maintenance.
Guides for diagnosing and resolving common lift operational problems.
Table of symptoms, causes, and remedies for lift operational issues.
Interpreting the LED status indicator for pump solenoid health.
Step-by-step guide for replacing the bridgeplate (inner rollstop) cable assembly.
Diagram showing the actuation states of limit switches during lift operation.
Adjusting the bridgeplate position for proper sensor engagement.
Procedure for setting the stow lock mechanism for secure platform storage.
Instructions for replacing the parallel arm spring assembly.
Steps for replacing the hydraulic cylinder gland nut and piston.
Schematic illustrating the hydraulic system components and flow.
Diagrams and legends for the lift's electrical system connections.
Explanation of wire color codes, connector types, and diagram labels.
Table listing wire colors corresponding to specific letters.
Description of Molex electrical connectors used in the system.
Definitions and commands for labels used in electrical diagrams.
Detailed wiring schematics for the lift's electrical system.
List of model numbers and associated kit numbers for Ricon Titanium lifts.
References to figures containing exploded views of lift assemblies and part locations.
Diagram showing locations of decals for S-Series Public Use lifts.
Diagram showing locations of decals for K-Series Public Use lifts.
Diagram and part list for the lift's control pendant assembly.
Diagram and part list for the lift's hydraulic pump assembly.
Diagram and part list for the lift's hydraulic system components.
Diagram and part list for the lift's electrical system components.
Diagrams showing parts of the lift's traveling frame assembly.
Diagrams showing parts of the S-Series platform assembly.
Diagrams showing parts of the K-Series platform assembly.
Diagram and part list for the lift's handrail assembly.
Technical specifications for Ricon Titanium S-Series and K-Series lifts, including dimensions and capacity.
General| Brand | Wabtec |
|---|---|
| Model | Ricon TITANIUM S Series |
| Category | Lifting Systems |
| Language | English |
