Error flags
Bit 0 = Eeprom writing error
Bit 1 = Eeprom reading error
Bit 2 = Cold junction error
Bit 3 = Process error (sensor)
Bit 4 = Generic error
Bit 5 = Hardware error
Bit 6 = L.B.A.O. error
Bit 7 = L.B.A.C. error
Bit 8 = Missing calibration data error
RO 0
1015 Cold junction temperature (degrees.tenths) RO -
1016
Start / Stop
0 = Controller in STOP 1 = Controller in START
R/W 0
1017
Lock conversion ON / OFF
0 = Lock conversion off 1 = Lock conversion on
R/W 0
1018
Tuning ON / OFF
0 = Tuning off 1 = Tuning on
R/W 0
1019
Automatic / manual selection
0 = Automatic 1 = Manual
R/W 0
1020 T.A. current ON (Ampere with tenths) RO 0
1021 T.A. current OFF (Ampere with tenths) RO 0
1022 OFF LINE* time (milliseconds) R/W -
1023 Instant Current (Ampere) RO 0
1024 Digital Input State RO 0
1025
Tune management for control loop 1
With automatic Tune (par. 73
t u n.1
= Auto):
0= autotuning function OFF 1= autotuning in corso
RO 0
With manual Tune (par. 73
t u n.1
=
manu.
o
OncE
):
0= autotuning function OFF 1= autotuning ON
R/W 0
With synchronized Tune (par. 73
t u n.1
=
SYncH.
):
0= autotuning function OFF
1= command output OFF (forced cooling)
2= command output ON (forced heating)
3= autotuning ON
4= autotuning finished
R/W 0
1026 Zero tare AI1 (1 = tare; 2 = reset tare) R/W 0
1099 Process subjected to the visualization filter and decimal point selection RO 0
1100 Process with decimal point selection RO 0
1101 Setpoint 1 with decimal point selection R/W EEPROM
1102 Setpoint 2 with decimal point selection R/W EEPROM
1103 Setpoint 3 with decimal point selection R/W EEPROM
1104 Setpoint 4 with decimal point selection R/W EEPROM
1105 Alarm 1 with decimal point selection R/W EEPROM
1106 Alarm 2 with decimal point selection R/W EEPROM
1107 Alarm 3 with decimal point selection R/W EEPROM
1108 Gradient Setpoint with decimal point selection RO EEPROM
1109 Percentage heating output (0-1000) R/W 0
1110 Percentage heating output (0-100) R/W 0
1111 Percentage cooling output (0-1000) RO 0
1112 Percentage cooling output (0-100) RO 0
* If value is 0, the control is disabled. If different from 0, it is the max. time which can elapse between two pollings before the
controller goes off-line. If it goes off-line, the controller returns to Stop mode, the control output is disabled but the alarms are
active.
