Wachendorff URDR001A - Environmental Policy; WEEE; Model Identification; Technical Data; General Features

7 - URDR001A - User manual
1.4 Environmental policy / WEEE
Do not dispose electric tools together with household waste material.
According to European Directive 2012/19/EU on waste electrical and electronic equipment and its
implementation in accordance with national law, electric tools that have reached the end of their life
must be collected separately and returned to an environmentally compatible recycling facility.
2 Model Identification
Power supply 24..220 VAC/VDC ±10% 50/60 Hz – 3 Watt
URDR001A
1 A.I. + 1 relays 5 A + 1 relays 3 A + 1 relay 2 A + 2 SSR + 2 D.I. + 1 A.O. V/mA +
RS485 + CT
3 Technical Data
3.1 General Features
Displays 4 digits 0,52’’, 5 digits 0,30’’
Operating temperature Temperature: 0-45° C -Humidity 35..95 uR%. Max. altitude: 2000m
Sealing Open type, IP20 (not UL evaluated)
Material Box and front panel PC UL94V0
Weight Approx. 210 g
3.2 Hardware Features
Analogue
inputs
AI1: configurable via software.
Input: Thermocouple type K, S, R, J,T,E,N,B.
Automatic compensation of cold junction
from -25..85° C.
Thermoresistances: PT100, PT500, PT1000,
Ni100, PTC 1K, NTC 10K (β 3435K)
Input V/mA: 0-1 V, 0-5 V, 0-10 V, 0-20 o 4-20
mA, 0-60 mV.
Pot. Input: 1...150 KΩ.
CT: 50 mA.
Tolerance (25° C)
± 0.2% ±1 digit (on F.s.) for thermocou-
ple, thermoresistance and V/mA.
Cold junction accuracy 0.1° C/°C.
Impedence:
0-10 V: Ri>110 KΩ
0-20 mA: Ri<5 Ω
0-40 mV: Ri>1 MΩ
Relay outputs Config. as command and alarm output
Contacts:
Q1: 5 A - 250 VAC for resistive load.
Q2: 3 A - 250 VAC for resistive load.
Q3: 2 A - 250 VAC for resistive load.
SSR outputs Config. as command and alarm output 12/24 V, 25 mA.
Analogue
output
Configurable as command
and alarm output or as retransmission of
process / setpoints.
Configurable:
0-10 V with 40000 points +/-0.2% (on
F.s.) @25 °C; load >= 1 KΩ
4-20 mA with 40000 points +/-0.2% (on
F.s.) @25 °C; load <= 250Ω
Power-supply
Extended power-supply 24..220 VAC/VDC
±10% 50/60 Hz
Consumption: 3 Watt
3.3 Software Features
Regulation algorithms
ON-OFF with hysteresis.
P, PI, PID, PD with proportional time
Proportional band 0..9999°C o °F
Integral time 0,0..999,9 sec (0 excludes)
Derivative time 0,0..999,9 sec (0 excludes)
Controller functions
Manual or automatic Tuning, selectable alarm, protection of command
and alarm setpoints.
