11 Maintenance
44
Installing air cleaner cartridge
1. Insert air cleaner cartridge.
2. Replace air cleaner cap.
3. Tighten all nuts of the air cleaner cap securely with a screw wrench.
11.3.4 Lubricating the machine
1. Remove any dirt around the zerk fitting.
2. Place filled manual grease gun onto the zerk fitting and operate approx.
20 times.
Note: Only use special lubricants for lubricating, see chapter Technical Data.
3. Wipe the area around the zerk fitting with a clean cloth.
NOTICE
Operating the engine without air cleaner can cause rapid engine wear.
f Do not run the engine without an air cleaner or air cleaner cap.
Item Designation
1 Zerk fitting
