Maintenance
Maintenance work 9.3
37
[us] | 07/2021 | 5100060589 | BPS | Operator’s Manual
1. Pull out spark plug connector.
2. Remove dirt from the spark plug area.
3. Unscrew spark plug and check.
4. Replace if damaged or heavily soiled.
5. Measure electrode spacing 1, see Technical Data on page 42.
ð Correct the electrode spacing by carefully bending it.
6. Tighten the spark plug again, tightening torque 18 Nm.
7. Plug the spark plug connector onto the spark plug.
9.3.8 Retightening and changing the V-belt
Carrying out preparations:
1. Place the machine on a level surface.
2. Decommissioning the machine.
3. Let the machine cool down.
Tighten the V-belt
1. Remove the V-belt guard.
2. Unscrew the screws of the exciter V-belt pulley.
3. Remove outer V-belt pulley half.
4. Remove the intermediate pulley.
5. Align and secure the removed intermediate pulleys and the outer V-
belt pulley half.
Information
When tightening, turn the V-belt pulley to prevent the V-belt from jam-
ming.
1. Tighten the screws.
2. Fit the V-belt guard, tightening torque 10Nm.
9
