Wacker Neuson BS 70-2 Repair Manual

Engine and Upper Machine Components Repair
30 wc_tx001546gb.fm
4.3 Replacing the Throttle Control (2010 4-stroke models)
Requirements
• Machine shut down and cool
• Torque wrench
Removal
Perform the procedure below to remove the throttle control.
4.3.1 Remove the silencing cover. See topic Removing the Silencing Cover.
4.3.2 Disconnect the throttle cable at the swivel (a) and the clamp (b).
4.3.3 Remove the clamp
(c).
4.3.4 Clip the wire ties (d).
4.3.5 Remove the bolt
(h) and hardware (b).
