Rammer Repair Ramming System
wc_tx001547gb.fm 91
5.1.20 Fasten the guide cylinder to the crankcase. Apply Loctite 243 and
torque the screws to 43 Nm (32 ft.lbs.).
5.1.21 Lay the rammer flat on the ground and align the protective pipe with
the upper machinery.
5.1.22 Position the clamps so that the clamp screws (k) are in line with the
sightglass (m).
5.1.23 Tighten the clamps and torque them to 13.5 Nm (10 ft.lbs.).
5.1.24 Fill the ramming system with clean oil as described in section
Ramming System Lubrication.
5.1.25 Run the rammer for several minutes and check it for oil leaks around
the guide cylinder and the bellows.
