7 Transport
34
100_0202_tr_0006.fm
Lifting and tying down the machine
Note: Designate a flagman for safe lifting.
1. When lifting the machine, attach suitable lifting tackle to the central suspen-
sion.
2. Load machine carefully in or on a viable and safe means of transport.
3. After loading, tie down the machine so that it is secured against rolling, sliding
and tipping over. Tie down using the provided tie-down lugs.
Pos. Designation Pos. Designation
1 Central suspension 2 Securing eyelets
Pos. Designation
1Belt
