8 Operation and use
35 100_0202_op_0011.fm
8.4.2 Operating a remote-controlled machine
The following table shows how the machine moves when the respective joystick of the remote
control is operated:
Moving and stopping the machine
1. Press the joystick of the remote control to the desired position and hold. The machine starts vibrating
and moves in the desired direction – the further the joysticks are pushed forward or backward, the
faster the machine moves.
2. Release both joysticks of the remote control. The machine stops moving and vibrating – after approx.
6 seconds, the engine switches to idle.
Switch slow/fast mode on and off
1. Press slow/fast mode button to switch between slow and fast operation.
When the receiving units flash yellow, the machine is in slow mode.
Switching stand vibration on and off
1. Pressing and holding stand vibration button – The machine compresses on the spot without moving
in one direction.
2. Releasing stand vibration button – The machine will return to normal operating condition.
8.4.3 Machine protection – installation
To protect the machine, an warning is activated when compacting:
The red control lamps on the center pole flash.
The receiving units flash red.
In addition, a machine response can be set in the configuration menu:
Switching off the machine.
Switching to slow mode.
Reduced power operation.
No movement
Forward Reverse
Forward left turn Forward right turn
Reverse left turn Reverse right turn
Left stand rotation Right stand rotation
NOTE
Fast operation is selected by default.
The slow mode is only intended for traversing highly compressed or hard surfaces.
