Wacker Neuson DV100 User Manual

9-8 BA D24 en/us* 1.0 * D24_1_0_900.fm
9 Technical data
Fuses/
relays
Rated current Protected circuits
F001 60A Switched power consumers
F002 80A Preheating
F003 50A 12 V 30
F004 50A 12V15, 12V15_1, 12V30
F005 7.5A Clearance light (left)
F006 7.5A Clearance light (right)
F007 30A Engine ECU 12 V 30
F008 10A Drive ECU 12 V 30
F009 5A CPU drive ECU 12 V 30
F010 15A Working light for drive unit, working light for loader unit
F011 5A Drive ECU 12 V 15, engine ECU 12 V 15
F012 10A
Display element + camera, switch lighting, relay coils, telematics 12 V 15,
drive interlock 12 V 15, radio 12 V 15
F013 10A Turn indicators
F014 15A Rotating beacon, hazard warning light
F015 10A
Telematics, drive interlock, position light, rear lights, license plate lighting,
trailer
F016 10A Radio, interior lighting
F017 15A Window wiper, washer pump
F018 30A Heating fan
F019 25A Air condition coupling, fan condenser
F020 15A 12 V socket
F021 15A Horn, brake lights
F022 10A Low beam
F023 10A High beam
F024 5A Reversing light, backup warning system
F025 15A Fuel pump
F026 10A Optional plug 12 V 15
F027 10A Optional plug 12 V 30
V001 DIODE 1A Blocking diode
V002 DIODE 1A Blocking diode
V003 DIODE 1A Blocking diode
V004 DIODE 1A Blocking diode
K001 Relay 70A Switched power consumers
K003 Relay 20/35A Reversing light, backup warning system
K003.1 Relay 20/35A Shutdown of the reversing light
K005 Relay 70A Preheating
K010
Turn indicator
relay 180 W
Turn indicators
