Technical data 9
Bulbs
K030 Relay 20/35A Brake lights
K062 Relay 20/35A Low beam
K063 Relay 20/35A High beam
K087
Time lag relay
0.75s
Start time lag relay
K088 Relay 20/35A Fuel pump
K114 Relay 20/35A Rotating beacon
K130 Relay 20/35A Horn
K131 Relay 20/35A 12 V 15
K146 Relay 20/35A Green rotating beacon
Fuses/
relays
Rated current Protected circuits
DV 60/90/100
Working lights/roof lights H3 12 V/55 W
Interior light Festoon lamp 12 V/5 W
Rotating beacon LED 9W
Turn indicators P21W
Clearance light LED/P21W
Parking light T4W 12 V/4 W
Low beam H3 12 V/55 W
Rear lights R10W
Reversing light P21W
Brake lights P21W
