Wacker Neuson DW90 User Manual

BA D18 us* 1.1 * D18t900.fm 9-7
Technical data 9
Fuses/
relays
Rated cur-
rent
Protected circuits Tier III Protected circuits Tier IV
F901 50A
Fuel pump Engine control unit
Starter, machine control unit 12 V 30 and 12 V 15,
lights, multifunctional display, radio,
wiper
2
, air conditioning, clearance lights
1
, hazard warning system
1
F902 50A
--- Diagnosis connector
Starter plus 12 V 15, preheating, cutoff solenoid, drive control unit,
reversing light
1
, reversing signal
1
, low beam
1
, high beam
1
, turn indicators
1
, air con-
ditioning
F4 10A
Cutoff solenoid
Diagnosis connector, water separator,
PCM regeneration switch
switched starter plus 12 V 15_1, fuse relay K1
F5 5A Fuel pump
Engine control unitF6 15A Additional start quantity
F7 15A ---
F8 10A Horn
1
F9 10A Horn
1
, rotating beacon
1
F10 10A Brake lights
1
F11 15A Starter
F12 15A Wiper
2
, radio12 V 15
2
F13 15A Heating
2
F14 15A High beam
1
F15 15A Working light
F16 15A
Diagnosis connector, camera display
3
, machine control unit 12 V 15,
control lever push buttons, operator presence switch
F17 10A Radio 12 V 30
2
, interior light
2
F18 15A Low beam
1
F19 10A Reversing lights, reversing signal
1
F20 10A Drive control unit
F21 20A Clearance lights
1
F22 10A Turn indicator 12 V 15
1
F23 10A Machine control unit 12 V 30, hazard warning system
1
F24 10A Clearance lights (left)
1
F25 10A Clearance lights (right)
1
K901 Relay Switched starter plus 12 V 15_1
K902 Relay Preheating Air conditioning
2
