9-14 BA D18 us* 1.1 * D18t900.fm
9 Technical data
9.13 Weight
Machine weights
Information
The weight specified here corresponds to the maximum configuration. The
actual machine weight depends on the selected options and can be read
off the type label.
Weight indications can vary by +/ 2%.
Ground clearance
Front skip ROPS DW60 kg/lbs DW90 kg/lbs DW100 kg/lbs
Transport weight
1
1. Transport weight: machine + 10 % fuel capacity.
4532 (9,991) 5232 (11,534) 5277 (11,634)
Operating weight
2
2. Operating weight: machine + full fuel tank + skip + operator (75 kg/165 lbs).
4614 (10,172) 5314 (11,715) 5359 (11,815)
Front skip cabin DW60 kg/lbs DW90 kg/lbs DW100 kg/lbs
Transport weight
1
4732(10,432) 5432 (11,976) 5477 (12,075)
Operating weight
2
4814 (10,613) 5514 (12,156) 5559 (12,255)
Swivel skip ROPS DW60 kg/lbs DW90 kg/lbs DW100 kg/lbs
Transport weight
1
4919 (10,845) 5664 (12,487) --
Operating weight
2
5001 (11,025) 5746 (12,668) --
Swivel skip cabin DW60 kg/lbs DW90 kg/lbs DW100 kg/lbs
Transport weight
1
5119 (11,285) 5864 (12,928) --
Operating weight
2
5201 (11,466) 5946 (13,109) --
DW60/LRC DW60/DW60 P DW90/100 option
Ground clearance 369 mm (14.53 in) 406 mm (15.98 in)
