Technical data 9
Values
DW60 standard DW90 DW100
mm (in) mm (in) mm (in)
A1 Height including rotating beacon
Rollbar 3350 (10'-12'') 3405 (11'-2'') 3595 (11'-10'')
Cabin 3215 (10'-7'') 3270 (10'-9'') 3460 (11'-4'')
A2 Height without rotating beacon
Rollbar 3110 (10'-2'') 3165 (10'-5'') 3355 (11'-0'')
Cabin 2998 ((9'-10'') 3055 ((10'-0'') 3245 (10'-8'')
A3
Height with lowered rollbar/
without cabin
2300 (91) 2355 (93) 2545 (8'-4'')
A4 Height of lowered rollbar 2185 (86 2240 (88) 2430 (96)
B1 Length without maneuvering coupling 4475 (14'-8'') 4660 (15'-3'')
B2 Length with maneuvering coupling 4575 (15'-0'') 4760 (15'-7'')
B3 Length with lowered rollbar 4945 (16'-3'') 5550 (18'-3'') 5130 (16'-10'')
C1 Machine width 2250 (89) 2465 (97)
C2 Skip width 2330 (92) 2495 (98) 2490 (98)
C3
Rollbar width/
cabin inclduing outside mirrors
Rollbar 1520 (60 1520 (60)
Cabin 1585 (62) 1585 (62)
D Track 1810 (71) 1920 (76)
E Wheelbase 2485 (98) 2700 (8'-10'')
F Ground clearance 369 (15) 406 (16)
G1 Tilt-out reach 610 (24) 555 (22)
G2 Tail-end lateral projection 1190 (47)
H1 Height of dump edge of skip (skip not tilted out) 1680 (661) 1745 (69)
H2 Height of upper edge of skip (skip not tilted out) 2020 (80) 2250 (89) 2300 (91)
H3 Height of dump edge of skip (skip tilted out) 460(18) 495 (20)
H4 Height of upper edge of skip (skip tilted out) 2490 (98) 2755 (9'-0'')
K1 Tilt angle 43° 47°
