Technical data 9
Values
DW60 DW60 3 m skip
1
DW90
mm (in) mm (in) mm (in)
A1 Height including rotating beacon 3215 (10'-7'') 3460 (11'-4'')
A2 Height without rotating beacon 2998 (9'-10'') 3245 (10'-8'')
A3 Height without cabin 2300 (91) 2545 (8'-4'')
B1 Length without maneuvering coupling 4835 (15'-10'') 4670 (15'-4'') 5085 (16'-2'')
B2 Length with maneuvering coupling 4935 (16'-2'') 4770 (15'-8'') 5185 (17'-0'')
C1 Machine width 2250 (88.58) 2465 (97)
C2 Skip width 2090 (82.28) 2275 (90)
C3 Width including outside mirrors 1585 (62)
D Track 1810 (71) 1920 (76)
E Wheelbase 2485 (98) 2700 (8'-10'')
F Ground clearance 369 (15) 406 (16)
G1 Tilt-out reach 505 (20) 490 (19) 480 (19)
G2 Tail-end lateral projection 1190 (47)
H1 Height of dump edge of skip (skip not tilted out) 1725 (68) 1730 (68) 1805 (71)
H2 Height of upper edge of skip (skip not tilted out) 2075 (82) 2305 (91)
H3 Height of dump edge of skip (skip tilted out) 1080 (43) 1175 (46) 1170 (46)
H4 Height of upper edge of skip (skip tilted out) 3525 (11'-7'') 3865 (12'-8'')
K1 Tilt angle 48° 40°
K2 Angle of rotation 90°
K3 Lateral tilt-out reach 115 (5) 100 (4) 190 (7)
1. Legislation in some countries requires a specific distance between the center of the steering wheel and the front edge of the machine. This distance is main-
tained with the optional 3 m skip.
