Wacker Neuson E13-01 User Manual

5-20 BA EZ17 en* 1.1 * ez17b510.fm
5 Operation
.
1. Raise the control lever base.
2. Make sure that the lever A located to the left under the operator’s seat
is in position 1.
3. Lower the control lever base.
4. Using the boom and dozer blade, raise the vehicle so that it is no
longer in contact with the ground and no foreign body is in the travel
gear during extension or retraction.
5. Raise the control lever base.
6. Set lever A in position 2.
7. Lower the control lever base.
Position Function
1 The dozer blade is actuated.
2 The telescopic travel gear is actuated.
Fig. 96
1 2
A
Fig. 97
Fig. 98
1
2
A
Fig. 99
