BA EZ17 en* 1.1 * ez17b510.fm 5-21
Operation 5
8. Set the travel gear to the desired position.
9. Raise the control lever base.
10.Set lever A in position 1.
Information
In order to ensure maximum stability during work:
► Only perform work with an extended telescopic travel gear.
► Lower the stabilizer blade and turn out the extensions.
B
Fig. 100
Telescopic travel
gear
Position
Extend Push lever B forwards.
Retract Pull lever B backward
Fig. 101
1 2
A
