Wacker Neuson E13-01 User Manual

5-46 BA EZ17 en* 1.1 * ez17b510.fm
5 Operation
AUX V (option)
Grab operation on the left:
1. Fit lever A onto the ball-type cock.
2. Set the ball-type cock to position B.
➥ The 90° notch indicates that grab operation is set.
3. Remove the lever after the changeover.
Right side grab operation:
1. Fit lever A onto the ball-type cock.
2. Set the ball-type cock to position B.
➥ The 90° notch indicates that grab operation is set.
3. Remove the lever after the changeover.
Fig. 152
A
90°
B
Fig. 153
A
9
0
°
B
