Wacker Neuson E13-01 User Manual

7-18 BA EZ17 en* 1.1 * ez17w700.fm
7 Maintenance
Raising the operator seat
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover.
3. Pull out and hold lock A, and raise the operator seat.
➥ The operator's seat is unlocked.
Locking the operator seat
1. Press and hold seat belt buckle A outward.
2. Fold the operator's seat back until it locks into place.
➥ The operator's seat is locked if it cannot be raised any more at the
backrest.
3. Close and lock the engine cover.
Battery cover
Opening:
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Remove the screw A and remove the battery cover.
Closing:
1. Install the cover and tighten screw A.
A
Fig. 201
A
Fig. 202
Fig. 203
A
B
