7-20 BA EZ17 en* 1.1 * ez17w700.fm
7 Maintenance
6. Remove the electric connector B if it is installed on the machine. The
connector is located on the left behind the operator seat.
7. Install the lifting gear at the points provided for lifting the machine. The
mandatory length L is a minimum 1300 mm (51 in).
8. Apply tension to the canopy with the lifting gear.
Danger of crushing due to pre-tensioned canopy!
The pre-tensioned canopy can cause serious injuries.
► Pay attention to the movements of the pre-tensioned canopy as you
remove the screws.
9. Remove the screws C.
➥ Fold up the operator's seat to improve access if necessary.
