BA E16 en* 1.0 * E16_10_510.fm 5-25
Operation 5
Dozer blade
Crushing hazard due to unintentional actuation!
Unintentional actuation can cause serious injury or death.
► Raise the control lever base.
► Lower the stabilizer blade to the ground after the work shift.
► Do not allow anyone to stay in the danger zone.
Lowering the stabilizer blade too deeply into the ground can create
increased resistance.
► Slightly raise the stabilizer blade. The clearance between the stabilizer
blade and the ground should be about 1 cm (0.4 in).
► Check the stabilizer-blade position before performing vehicle travel.
In order to achieve the best possible stability, lower the stabilizer blade.
The stabilizer blade is also used as a parking brake. Press the stabilizer
blade against the ground.
Stabilizer-blade lever
Stabilizer blade Position
Raise Pull lever A backward
Lower Push lever A forward
