Wacker Neuson E16-02 User Manual

5-30 BA E16 en* 1.0 * E16_10_510.fm
5 Operation
Additional control circuits
AUX I
The auxiliary hydraulics system is operated with the right control lever.
AUX II (option)
The auxiliary hydraulics system is operated with the left joystick.
Tier IV: If the AUX II function is selected, the next symbol appears in the
center of the display for a few seconds.
Fig. 164Fig. 164
B
Oil flow Position
To the line on the left Press switch B to the left
To the line on the right Press switch B to the right
B
Fig. 165
Oil flow Position
To the line on the left Press switch B to the left
To the line on the right Press switch B to the right
Fig. 166
